Electrónica Co., Ltd de Shenzhen Shichuangxinke
el profesional hace buena calidad, proporciona el producto perfecto y el servicio para cada cliente.
 |
| Lugar de origen: | China |
| Nombre de la marca: | SCXK |
| Certificación: | CE/ROHS/FCC/ISO/UL |
| Número de modelo: | P3.91 |
| Cantidad de orden mínima: | sqm 10 |
|---|---|
| Precio: | negotiation |
| Detalles de empaquetado: | caja de la madera contrachapada, caso del vuelo, usted elige de lo que usted tiene gusto. |
| Tiempo de entrega: | 7-15 días laborables |
| Condiciones de pago: | T/T, Western Union, MoneyGram |
| Capacidad de la fuente: | 5000sqm por mes |
| Uso:: | Vídeo del juego | Color:: | RGB |
|---|---|---|---|
| Tamaño del panel:: | 250*250m m | Echada del pixel:: | 3,91 |
| Certificado:: | CE/ROHS/ISO9001/CCC | Microprocesador llevado:: | Epistar |
| Brillo: | 1200cd/sqm | Frecuencia de actualización:: | 1920Hz-3840Hz |
| Tamaño de gabinete:: | 500x500m m | Densidad del pixel:: | 65410dots/m2 |
| Tipo del LED:: | SMD2121 (3in1) | Vida:: | 100000hours |
| Alta luz: | Exhibición del fondo de la etapa LED de SCX,1200cd/sqm exhibición del fondo de la etapa LED,SMD2121 llevó la pantalla de la etapa de la iglesia |
||
Product description
As we all know our human is an visual creature ,everyone enjoy this beautiful and colorfu world l, and led display screen can provide pelope much more Visual enjoyment,then p3.91 led display is one high density and quality product of it,let’s start a visual feast together!
Module Parameter:
| Pixel pitch | 3.91mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD 2121 |
| Module size | 250x250mm |
| Module weight | 0.35kg |
| Module resolution | 64x64dots |
| Module quantity per cabinet | 4pcs |
Cabinet Parameter:
| Cabinet size | 500x500mm |
| Cabinet material | die- casting aluminum |
| Cabinet weight | 6.5kg |
| Cabinet resolution | 128x128 dots |
| Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter
| Pixel density | 65410dots/m² |
| Brightness | ≥1200 cd/m² |
| Viewing angle | H≥120° V≥120° |
| Min.viewing distance | 3.9m |
| Max.power consumption | 890W/m² |
| Avg.power consumption | 330 W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 65536 |
| Refresh rate | ≥1920Hz |
| MTBF | ≥50000 hours |
| Lifespan | ≥100000 hours |
| Operating temperature | -10℃ ~ +60℃ |
| Storage temperature | -20℃ ~ +60℃ |
Control System Parameter:
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way | Computer, video-synchronous, real-time, off-line, internet etc. |
Cabinet
company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
Certificate
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
FAQ
Q:Are you a factory or a foreign trade company?
A:We are factory, located in Shenzhen China. We have our own factory and welcome you to visit us.
Q: Where is outdoor LED display screen used for?
A: Outdoor rental use. Widely used for backdrop of staging event, rental business, live-show, concert, etc. Outdoor fixed
installation use, outdoor advertising.
Q:In what way I can pay you the order?
A:T/T,Western Union,L/C are available to us.
Q:What is the lead time?
A:Honestly, it depends on the order quantity, in general within 10˜15 days.
Q:How many years warranty can you offer?
A:We work in producing the best quality products with 1-2-year-warranty and whole life service for you.
Q:Do you have discount for your products?
A:Discount will be offered according to order quantities.
